The APM WC67K series CNC hydraulic press brake is engineered for both wire mesh fabrication and general sheet metal work. With purpose-built dies it forms mesh panel frames and the hooked edges (tension strips) of vibrating screen media — including an induction-heating bending process for high-carbon crimped mesh — while standard V-dies handle everyday plate bending up to 168 tons.
Precision CNC Back Gauge: Ball screw and linear guide driven by dual servo motors, positioned by CNC with 0.01 mm minimum readout and travel limit switches at both ends.
Crowning (Deflection) Compensation: Wedge-type compensation mechanism offsets ram and table deflection under load, keeping bend angles consistent across the full working length.
Dual Synchronization: Torsion shaft plus combined mechanical-hydraulic synchronization gives high parallelism and strong anti-eccentric-load capability; final ram positioning is set by mechanical stops inside the cylinders.
Branded Core Components: Estun CNC controllers (E21 / E30 / TP-10S / DA-41 options), Siemens and Schneider electrics, ATOS hydraulic valves, and VALQUA cylinder seals.
Rigid All-Steel Frame: Fully welded steel construction, vibration stress-relieved, machined in a single setup on a CNC floor boring-milling machine for accurate parallelism and squareness.
Flexible Operation: Jog, single-stroke, and mid-stroke stop modes with both manual and foot pedal control; segmented top dies allow mixed-length tooling setups for varied bend angles.
Mesh-Specific Tooling: Optional mesh-frame bending dies and screen hook-strip dies, plus custom-designed punches and V-dies (hardened and tempered) made to your drawings.
Item | Specification | Unit |
Nominal force | 1000 / 1280 / 1680 | kN |
Worktable length | 2500 / 3200 | mm |
Distance between housings | 2000–2500 | mm |
Side plate thickness | 50–60 | mm |
Throat depth | 320 (standard) / 500 (extended) | mm |
Ram stroke | 150–200 | mm |
Stroke adjustment range | 120–180 | mm |
Open height (table to ram) | 400 | mm |
Approach speed | 80 | mm/s |
Working speed | 6–8 | mm/s |
Return speed | 60–80 | mm/s |
Back gauge resolution | 0.01 | mm |
CNC system options | E21 / E30 / TP-10S / DA-41 (Estun) | — |
Main motor | Y2-160M-4, 7.5–11 kW | — |
Hydraulic pump | NB3-G25F/32F high-pressure pump | 1 set |
Cylinders | Adjustable square-body cylinders | 2 sets |
Standard top die | T8/70 steel, 150×26×2500 (3 segments) | 1 set |
Standard bottom die | T8/70 steel, 125×125×2500 | 1 set |
Machine dimensions (L×W×H) | 2680 × 1600 × 2518–2618 | mm |
Power supply | 380V/50Hz 3-phase — voltage customizable by country | — |
Model | Nominal Force | Table Length | CNC Options | Weight |
WC67K-100T×2500 | 1000 kN | 2500 mm | E30 | 6.0 t |
WC67K-128T×3200 | 1280 kN | 3200 mm | TP-10 | 7.5 t |
WC67K-168T×2500 | 1680 kN | 2500 mm | E21 / E30 | 8.5 t |
WC67K-168T×3200 | 1680 kN | 3200 mm | TP-10S | 9.0 t |
Bending wire mesh panel frames and edge profiles for screening and filtration assemblies
Forming hooked tension strips on vibrating screen media, including induction-heated bending of high-carbon crimped mesh
Folding perforated plate and punched mesh into trays, guards, and enclosures
General sheet metal bending: cabinets, brackets, HVAC components, and structural profiles
Built and inspected to Chinese machine tool standards JB 10148-1999 (press brake safety), GB/T 14349-93 (press brake accuracy), and JB/T 2257.1-92 (technical conditions). Welded frames are ultrasonic-inspected and vibration stress-relieved; key castings and forgings are flaw-detected before machining. Every machine carries a 12-month warranty from acceptance, with lifetime technical service at cost price and remote video support for fast troubleshooting.
We are glad to assist you with additional information. Tell us your material, bend length, and thickness — our engineers will size the tonnage and tooling for you.
Our specialists will guide you to the right solution for your needs.
